390011R92 - Pressure Plate: 11", w/ PTO disc, w/ 1.344" flywheel

All Products

clutch cover (2838)

CLUTCH KIT (411)

CLUTCH DISC (1421)

CLUTCH RELEASE BEARING (62)

clutch (15)

Diaphragm spring (4)

generators (1)

Brake lining (12)

brake shoe (34)

Fan Clutch (3)

Flywheel (1)

Place of Origin:	YANCHENG
Brand Name:	YCJH
Certification:	TS16949
Model Number:	390011R92 - Pressure Plate: 11", w/ PTO disc, w/ 1.344" flywheel

Minimum Order Quantity:	20 PCS
Price:	1.00
Packaging Details:	Neutral packaging or color box packaging
Delivery Time:	35-45 work days
Payment Terms:	TT
Supply Ability:	300000

Contact Now

Detailed Product Description

Fits YCJH-IH Tractor

Pos.	Part No	Qty	Parts name	Comments
YCJH-01	390011R91	[1]	PLATE ASSY.	IH PLATE ASSY, dual clutch pressure Superseded by part number: 390011R92
YCJH-02	179821	[6]	BOLT,Hex, 5/16" - 18 x 1 3/8", Gr 5	IH Superseded by part number: 413-522
YCJH-03	103320	[6]	LOCK WASHER,5/16"	IH WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
YCJH-04	392502R1	[3]	PIVOT PIN	IH PIN, pivot Superseded by part number: 3047750R1
YCJH-05	635495R1	[3]	SCREW	IH adjusting Superseded by part number: 635495R2
YCJH-06	392499R1	[3]	FINGER	IH LEVER, clutch Superseded by part number: 392499R2
YCJH-07	635494R1	[3]	VALVE SPRING	IH SPRING, retracting
YCJH-08	392503R1	[3]	PIN	IH stud rod
YCJH-09	635496R1	[3]	BLOCK	IH ROD, stud
YCJH-10	392504R1	[3]	PIN	IH SPRING, hair pin
YCJH-11	392497R1	[1]		P PLATE, back
YCJH-12	392500R1	[1]	SPRING	IH Belleville Superseded by part number: 635490R1
YCJH-13	635491R1	[1]	PLATE	IH pressure
YCJH-14	392492R91	[1]	DISC	IH ASSY, PTO driven
YCJH-15	392498R1	[1]	PLATE	IH flywheel
YCJH-16	392501R1	[1]	SPRING	IH Belleville Superseded by part number: 635490R1
YCJH-17	392496R1	[1]	PLATE	IH pressure
YCJH-18	114493	[6]	JAM NUT,Jam, 5/16"-24, G5	IH Superseded by part number: 86637933
YCJH-19	355106R1	[3]		P SCREW, cap
YCJH-20	392493R91	[1]	PACKAGE	IH clutch facing, consists of two facings and eight rivets, 392495R1 Superseded by part number: 392492R91
YCJH-21	392495R1	[8]		P RIVET, clutch facing
YCJH-22	399536R91	[1]	DISC	IH ASSY, clutch drive, will work for 390010R91 Superseded by part number: 399536R92
