13-inch Wheeled Tractor Clutch Assembly
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| High Light: | 13-inch Wheeled Tractor Clutch Assembly,13-inch Wheeled Tractor Clutch Assembly,13-inch Wheeled Tractor Clutch Assembly |
||
|---|---|---|---|
13-inch Wheeled Tractor Clutch Assembly
| Model | 13-inch Clutch Assembly |
| Type of Clutch | Independent Dual Stage |
| Outer/Inner Diameter of Friction Plate(mm) | φ327×φ193 (Major) |
φ329×φ200 (subsidiary) | |
| Number of Friction Surfaces | 2 |
| Friction Materials | non asbestos(Major) |
| Powder Metallurgy(subsidiary) | |
Dimension of Spline (number of teeth×modulus/spline width) | 16×2.65 |
| 10×2.6 | |
| Compressing Force | 12500-14000 |
| Compressing Method | Disk Spring |
| Connection Dimension | 6-φ11holes in uniform distribution on φ365diameter,φ377.9±0.1 seam allowance |
| Model of Assembling Tractor | 95-125 HP |
